SWP GenSet MPM 5/180 I-D/AE-Y Portable Diesel Welder Generator

Description

The GenSet MPM 5/180 is a reliable, portable and powerful diesel welder generator designed for professional welders. Featuring 170A welding current and 5kVA rated power, this generator is capable of welding a variety of materials and thicknesses and is suitable for tough construction jobs. Its diesel engine is fuel efficient and offers excellent run time, making it the perfect choice for demanding welding jobs.

• Warning lights for battery charger failure, and low oil pressure
• 12V battery
• Earth Leakage Circuit Breaker
• Power output protection
• 1 x 16A 110V single-phase EEC socket
• 1 x 16A 230V single-phase EEC socket
• 48V output
• Voltmeter

Specifications

• Noise level: 99 LWA (74dB @ 7m)
• DC Welding Duty Cycle: 35%:170A-27V | 40%:180A-20V | 60%:140A-26V
• DC Welding Output range: 40A-170A
• DC Welding Open Circuit Voltage: 90V
• DC Welding Max welding rod: 4mm
• AC Generator: 50Hz
• Type: Asynchronous, Self-Excited and Self-Protected
• Three-Phase power (stand-by): 5kVA-400V
• Three-Phase power (prime): 4.5kVA-400V
• Single-phase power: 4kVA-230V
• Single-phase power: 2kVA-110V
• Power factor: cos 0.8
• Diesel Engine: 3000 rpm
• Type: Yanmar L100V - Stage V - 1 cylinder - 435 cm3
• Cooling system: Air
• Starting system: Electric (12Vdc)
• Fuel tank capacity: 30 litres
• Fuel consumption @ 75%: 1.5 ltres/hour
• Insulation class: H
• Ambient temperature: 40°C
• Altitude: 1000m
• Mechanical protection: Ip23
• Dimensions (L x W x H): 950 x 480 x 574 mm
• Dry Weight: 148kg
